Benchtop microcontroller meter that reads pH, mV and temperature on a bright 3½-digit red LED display. 3-point automatic calibration at the touch of a button with pH 4.00, 7.00 and 9.20 buffers, which the meter recognises on its own, and automatic temperature compensation with the Pt-100 probe from 0 to 100 °C. Soft-touch membrane keypad and a rugged enamel-painted steel housing. Supplied with a combination pH electrode, Pt-100 temperature probe, pH 4.00, 7.00 and 9.20 buffer tablets and an electrode holder. 230 V AC.
Non-returnable
Downloads
Application Industry
PharmaceuticalFood, dairy and beveragesWater and environmentEducation and researchAgriculture and soil Parameters Measured
pHTemperaturemVORP Product Details
Specifications
Product Details
Product Details
The Hintron microcontroller pH, mV and temperature meter is a benchtop instrument for routine pH work in laboratories, production and quality control. One unit measures pH, mV and temperature, and calibration takes three button presses with standard buffers.
Measurement
- pH: 0 to 14.00 pH, resolution 0.01 pH, accuracy ±0.01 pH (relative)
- mV: 0 to ±1999 mV, resolution 1 mV, accuracy ±1 mV
- Temperature: −20 to +200 °C with the Pt-100 probe, resolution 0.1 °C, accuracy ±0.2 %
- Temperature compensation of pH: automatic with the Pt-100 probe, 0 to 100 °C
Calibration
- 3-point automatic calibration by push button
- The meter recognises the standard buffers pH 4.00, 7.00 and 9.20 on its own
General
- Display: 3½-digit bright red LED
- Keypad: 5 soft-touch membrane keys
- Housing: rugged enamel-painted steel
- Power: 230 V ±10 % AC, 50 Hz
Supplied with
- pH, mV and temperature meter
- Combination pH electrode
- Pt-100 temperature probe
- pH buffer tablets, pH 4.00, 7.00 and 9.20
- Electrode holder
- Operation manual
Intended for industrial and laboratory use only, not for clinical use.
Specifications
Specifications
Measurement
- CalibrationpH 3-point automatic, by push button · — · —
- Range0 to 14.00 pH · 0 to ±1999 mV · −20 to +200 °C
- Resolution0.01 pH · 1 mV · 0.1 °C
- Accuracy±0.01 pH (relative) · ±1 mV · ±0.2 %
- Temperature compensationAutomatic with the Pt-100 probe, 0 to 100 °C · — · —
- Buffer recognitionAutomatic for pH 4.00, 7.00 and 9.20 · — · —
- InputCombination pH electrode (supplied) · — · Pt-100 probe (supplied)
General
- Form factorBenchtop
- Display3½ digit red LED
- Power230 V ±10 % AC, 50 Hz
- HousingRugged enamel-painted steel
- Controls5 soft-touch membrane keys
